Based in Midland, UK, Aaron Sheets and Plates is a trusted manufacturer and supplier of premium metal products, specializing in stainless steel sheet plates We offer a wide range of products, including stainless steel 321 sheets and plates and are known for their resilience corrosion and high temperature stability. Ideal for rugged applications, our stainless steel 321 materials provide durability and performance. Focusing on quality and customer satisfaction, we offer customized solutions to meet the needs of a variety of businesses.
Stainless Steel 321 Sheet and Plates is an austenitic steel alloy that resists intergranular corrosion well, especially at elevated temperatures. Its composition is 17-19% chromium, 9-12% nickel and 0.5% titanium, making the product stable against carbide precipitation. Mechanical properties include tensile strength of 520-720 MPa, yield strength of 205 MPa, and elongation of about 40%. It also provides excellent weldability and oxidation resistance, making it ideal for high temperature applications such as in the aerospace, chemical and petrochemical industries, where corrosion resistance and thermal stability are important.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 321 sheets and plates have several key advantages, making them ideal for high temperature applications. They exhibit excellent resistance to oxidation, corrosion and carburization, especially at temperatures up to 900°C (1650°F). The titanium content improves the stability of the alloy and prevents carbide precipitation during welding, increasing its durability and strength. Stainless steel 321 is also highly resistant to stress corrosion cracking and provides excellent formability and weldability. These characteristics make it ideal for industries such as aerospace, chemical processing and power generation, where reliability and long-term performance are critical.
Stainless steel 321 sheets and plates are widely used in applications requiring corrosion resistance and high temperature stability. Common applications include aerospace components, such as turbine blades and exhaust systems, heat exchangers, reactors and other chemical processes in addition to energy production and petrochemical processes in weldments, pressure vessels and heat treated products around. The coating’s resistance to oxidation and stress corrosion cracking also makes it suitable for use in food processing, marine environments, and other harsh environments.
